Caster Wheel

About Caster Wheel

Caster Wheel

A) Foot Master Caster Wheels

Available Sizes:

1) 40F, Wheel Dia: 42mm, Size of Plate: 55x55 mm, Plate Hole Centers: 42x42 mm, Plate Hole: 6.5mm, Load Capacity-For 4 Wheels: 100 Kg,

2) 60F, Wheel Dia: 50mm, Size of Plate: 73x73mm, Plate Hole Centers: 58x58mm, Plate Hole: 7 or 8.5mm, Load Capacity-For 4 Wheels: 500 kg,

3) 80F, Wheel Dia: 63mm, Size of Plate: 90x90mm, Plate Hole Centers: 70x70mm, Plate Hole: 9mm, Load Capacity-For 4 Wheels: 1000 kg,

4) 100 F, Wheel Dia: 75mm, Size of Plate: 95x95mm, Plate Hole Centers: 70x70mm, Plate Hole: 11mm, Load Capacity-For 4 Wheels: 1500 kg,

5) 150F, Wheel Dia: 96mm, Size of Plate: 100x100mm, Plate Hole Centers: 70x70mm, Plate Hole: 13mm, Load Capacity-For 4 Wheels: 3000 kg.

B) Single ball Bearing PP Wheel Caster Wheels (With Plate)

Available Sizes:

1) Wheel Dia: 75mm (3 Inches), Plate Size: 91x63mm, Load Capacity/Nos: 70,

2) Wheel Dia: 100mm (4 Inches), Plate Size: 91x63mm, Load Capacity/Nos: 80,

3) Wheel Dia: 125mm (5 Inches), Plate Size: 91x63 mm, Load Capacity/Nos: 90.

C) Single ball Bearing PP Wheel Caster Wheels (With Screw)

Available Sizes:

1) Wheel Dia: 75mm (3 Inches), Thread Size: M12x25, Load Capacity/Nos: 70,

2) Wheel Dia: 100mm (4 Inches), Thread Size: M12x25, Load Capacity/Nos: 80,

3) Wheel Dia: 125mm (5 Inches), Thread Size: M12x25, Load Capacity/Nos: 90.

D) Plain bore Bearing PU Wheel Caster Wheels (With Plate)

Available Sizes:

1) Wheel Dia: 50mm (2 Inches), Plate Size: 59x47mm, Load Capacity/Nos: 22,

2) Wheel Dia: 63mm (2.5 Inches), Plate Size: 70x58mm, Load Capacity/Nos: 30,

3) Wheel Dia: 75mm (3 Inches),, Plate Size: 70x58mm, Load Capacity/Nos: 40.

E) Plain bore Bearing PU Wheel Caster Wheels (With Screw)

Available Sizes:

1) Wheel Dia: 50mm (2 Inches), Thread Size: M8x20mm, Load Capacity/Nos: 22,

2) Wheel Dia: 63mm (2.5 Inches), Thread Size: M12x25mm, Load Capacity/Nos: 30,

3) Wheel Dia: 75mm (3 Inches), Thread Size: M12x25mm, Load Capacity/Nos: 40.
